Understanding UL Class 2 vs. Class P: A Definitive Guide for North American Lighting Manufacturers

In the highly regulated North American commercial and industrial lighting market, navigating the labyrinth of safety certifications is a daily reality for Original Equipment Manufacturers (OEMs). Two of the most commonly encountered, yet frequently misunderstood, designations are UL Class 2 and UL Class P.

It is a common scenario in procurement meetings for a buyer to ask: "Should we buy a Class 2 driver or a Class P driver?" This question, however, reveals a fundamental misunderstanding of Underwriters Laboratories (UL) standards. These two classifications are not mutually exclusive, nor do they govern the same aspects of a power supply. They serve entirely different regulatory and engineering purposes.

This comprehensive technical whitepaper is designed for North American luminaire OEMs, electrical engineers, and supply chain directors. It will dismantle the misconceptions, deeply analyze the engineering constraints of UL 1310 (Class 2) and the supply chain agility of UL 8750 (Class P), and explain how mastering both can drastically reduce time-to-market and lower your Total Cost of Ownership (TCO).

Part 1: Decoding UL Class 2 — The Standard of Output Safety

When we talk about UL Class 2, we are talking exclusively about fire and electrical shock hazard prevention on the output side of the LED driver.

Regulated primarily under the UL 1310 standard (Standard for Class 2 Power Units), a Class 2 designation means that the power supply's output is inherently restricted to safe levels of voltage, current, and total power. The logic is simple: if the power output is physically incapable of delivering enough energy to start a fire or cause a lethal shock, the downstream components (like the LED modules and the connecting wires) require less stringent safety protections.

1.1 The Strict Electrical Limitations of UL Class 2

To achieve a UL Class 2 rating, an LED driver must possess internal circuitry that strictly limits its output under both normal operating conditions and single-fault conditions. The defining limits are:

• Maximum Power: 100 Watts per output channel. (You cannot have a single 150W Class 2 output).




• Maximum Voltage: Generally limited to 60 Volts DC (in dry/damp locations) or 30 Volts rms / 42.4 Volts peak (in wet locations).




• Maximum Current: Limited to 8 Amps (or strictly regulated to prevent overheating of standard wiring).

1.2 The OEM Advantage of Using Class 2 Drivers

Why do lighting manufacturers love Class 2 drivers? Because it radically simplifies luminaire design and lowers Bill of Materials (BOM) costs:

 1. Simplified Wiring Requirements: Because the output is deemed "touch-safe" and "fire-safe," the National Electrical Code (NEC) Article 725 allows for Class 2 output wiring to use lower-rated, thinner, and less expensive insulation (such as CL2 or CL3 rated cables).

 2. Reduced Enclosure Requirements: The LED modules and the connecting wires do not need to be enclosed in heavy-duty, fire-rated electrical conduit or grounded metal housings. This is the very reason why bare LED strip lights and suspended linear architectural fixtures can exist safely without thick metal casings.

 3. No Shock Hazard for Installers: Electricians can legally and safely handle the secondary (output) wiring without the risk of lethal shock, making field installations faster and safer.

1.3 The Limitation of Class 2

The 100-watt limit is the primary bottleneck. If an OEM is designing a 300W stadium floodlight or a high-mast street light, a single UL Class 2 driver is impossible. The OEM must either use a non-Class 2 driver (requiring heavy conduit and strict fire enclosures for the LED board) or use a multi-channel driver with three separate, isolated 100W Class 2 outputs.

Part 2: Unpacking UL Class P — The Catalyst for Supply Chain Agility

While Class 2 focuses on the output parameters, UL Class P (introduced as an enhancement within the UL 8750 standard) focuses on the thermal behavior and substitution flexibility of the driver itself.

The "P" stands for "Protected." The UL Class P program was created to solve a massive bottleneck in the lighting supply chain: the inability to swap LED drivers without re-certifying the entire luminaire.

2.1 The Problem Class P Solved

Historically, LED drivers were evaluated as "Recognized Components." When a luminaire OEM integrated a driver, UL required an In-Situ Temperature Measurement Test (ISTMT). Thermocouples were placed inside the luminaire to ensure the driver didn't overheat.

If the OEM wanted to switch driver brands due to a supply chain shortage or cost reduction, the new driver required a new ISTMT. This meant sending the fixture back to the lab, paying thousands of dollars, and waiting 6 to 8 weeks.

2.2 How UL Class P Works

A Class P driver is evaluated rigorously by UL as a standalone unit under abnormal thermal fault conditions (e.g., component short-circuits, blocked ventilation). UL ensures that no matter what fails internally, the driver possesses integrated thermal protection (like thermal foldback circuits) that prevents it from catching fire or melting.

Because it is "thermally self-protecting," UL assigns the driver a specific Temperature Case (Tc) point maximum rating (e.g., 90°C).

2.3 The OEM Advantage of Using Class P Drivers

The benefit of Class P is purely administrative and strategic: Plug-and-Play Substitution. If an OEM's original luminaire certification used a Class P driver that reached 75°C during the ISTMT, the OEM can swap it out for any other brand's Class P driver in the future, without laboratory re-testing, provided that:

 1. The new driver has identical electrical input/output ratings.

 2. The new driver has a rated maximum Tc equal to or greater than the 75°C measured in the original test.

 3. The environmental ratings (e.g., Damp/Wet location) match.

This turns a 6-week certification delay into a 6-day paperwork update, granting OEMs immense leverage in supply chain negotiations and risk mitigation.

Part 3: The Ultimate Misconception — "Class 2 vs. Class P"

The phrase "Class 2 vs. Class P" is technically a false dichotomy. They live on two different axes of engineering.

To clarify, let us look at the intersection of these two standards:

As shown above, the "Holy Grail" for most indoor commercial lighting manufacturers is a driver that is BOTH UL Class 2 and UL Class P. This provides the ultimate combination: the ability to use cheap, thin wiring and no fire enclosures (thanks to Class 2), combined with the ability to instantly swap driver suppliers if a chip shortage occurs (thanks to Class P).

Part 4: Strategic Impact on LED Board Design

The choice between these classifications heavily impacts how your electrical engineers design the actual LED light engine (PCBA).

Scenario A: Designing for Class 2

If you mandate a Class 2 driver, your engineers must design the LED board string configuration so that the Forward Voltage (Vf) never exceeds 60V DC. This often means placing more LEDs in parallel rather than a long series string. While this keeps the system touch-safe, parallel circuits can suffer from current imbalances if LEDs degrade unevenly.

Scenario B: Designing for Non-Class 2 (But Class P)

If you are designing a 200W industrial high-bay, you cannot use a single Class 2 output. You will select a Non-Class 2, Class P driver. Because the voltage limit is removed, your engineers can design a long series string of LEDs (e.g., driving them at 150V DC or 200V DC). High voltage/low current series strings are highly efficient and ensure perfect current matching across all LEDs. However, you must now design the luminaire housing to physically prevent a technician from touching the live LED board, using specialized grounding and robust optical covers.

Part 5: Navigating NEC Inspections and Compliance

Understanding these labels is critical not just for manufacturing, but for surviving on-site inspections by Authority Having Jurisdiction (AHJ) inspectors in North America.

 1. The NEC Article 725 Trap: Many electrical contractors prefer to run low-voltage wiring outside of conduits to save labor costs. If an inspector checks the driver and does not see the "UL Class 2" logo, they will flag the installation and demand that all secondary wiring be encased in metal conduit. This can halt a construction project instantly.

 2. The "Recognized" vs "Listed" Nuance: While Class P drivers can be either UL Recognized (UR) or UL Listed, a standalone Class 2 power supply is often UL Listed, meaning it can be mounted completely outside of the luminaire housing (e.g., hidden in a drop ceiling). If an OEM uses a driver that is only Class P (Recognized) but not Listed, it must be contained within the luminaire's grounded metal enclosure.

Mastering the Regulatory Matrix

For North American lighting manufacturers, the debate is never "Class 2 versus Class P." The goal is strategic alignment of your product roadmap with the correct UL pathways.

• Require UL Class 2 when you want to minimize the physical safety constraints on your luminaire design, use lighter materials, and provide contractors with touch-safe installations.




• Demand UL Class P on every driver you source—regardless of its power level—to secure your supply chain, prevent certification bottlenecks, and ensure you can pivot between driver brands in days rather than months.

By mastering the distinction and intersection of UL 1310 and UL 8750, procurement and engineering teams can forge a luminaire portfolio that is not only intrinsically safe but commercially unstoppable in a volatile global market.
